Dual Band Base Antenna Shark Fin Design Coaxial Cable Magnetic Mount

Shark Fin Design 144/430Mhz Dual Band Base Antenna with Coaxial Cable Magnetic Mount



This is an antenna which is convenient to carry and use; With 50w and 3dBi features, it can enhance the ability to receive signals, what’s more, it also has a significant effect in extending communication distance, 4 Coaxial connectors for easy use of hand-held walkie-talkie in the car. Shark Fin Design 144/430Mhz Dual Band Antenna with 4 Adapter for Baofeng UV-5R UV-82 UV-9R Plus Walkie Talkie Mobile Radio



Features:

1. Can install to the antenna base station directly.
2. PL-259 suitable for car mobile radio station.
3. Super short antenna, good concealment, effectively.
4. Ultra short built-in circuit board, signal to send and receive is strong.



VHF UHF Antenna:

Frequency: Dual Band136-174MHz & 400-470MHz

Gain: 2.5/3dB

Max Power: 50W

V.S.W.R: LESS 1.5

Connector: PL259 UHF Type

Antenna Height: 12cm

Color: Black



5M Coaxial Cable Magnetic Mount Base:

Length of Coaxial Cable: 5 Meter

Material: Copper cord

Color: Black


Compatibility:

for YAESU:

FT-1802M,FT-1807, FT-7900R, FT-1900R,FT-2900, FT-2800M, FT-7800R, FT-8800R,…

for Kenwood:

TM-271,TM-471,TM-281,TM-481,TK760,TK780,TK7160,TK7180,TK7102,TK7150 TK7302U,TK7360,NX700…

for ICOM:

IC-2200H,IC-2720H,F121S, F121, F5011, F5021, F5121D, F5061, F1721, F1821, F9511, V8000, V2300H,…

for Vertex:

VX2100,VX2200,VX4500,…

for TYT:

TH-9800,TH-7800,TH-9000

for Baofeng:

BF-9500..

for Wouxun:

KG-UV950P,KG-UV920P,…

for Baojie:

BJ-218 BJ-318

for QYT:

KT8900, KT-8900R,KT-8900D KT-7900D



And any other radio that uses PL259(SO-239 / SL16 / UHF-M) connector Antennas.


Note: If your radio model not listed above, please see my other item or email us your model number, then, we will help you find one that suit for you

Coaxial Connector:


4 Coaxial connectors for easy use of hand-held walkie-talkie in the car.

SMA-Female Connector / SMA-M Male Connector / BNC Connector support various hand-held walkie-talkie.

SO239 Male Connector support male antenna interface of the car radio.


Note: The product is equipped with four additional connectors to support more car radio and hand-held walkie-talkie that can reach 90%, but we can not guarantee support for all 100% of the walkie talkie, Old section and rare style walkie talkie may have no support phenomenon.



 Package includes:

1 x 144/430Mhz Dual Band Base Antenna Shark Fin Design
