TYT MD-2017 GPS Dual Band DMR/Analog 144/430 Radio
TYT MD-2017 GPS is a Analog/DMR Dual Band radio,compatible with Mototrbo Tier Ⅰ & Ⅱ Dual time slot .
The TYT MD-2017 takes the clarity and full quieting of digital voice communications to UHF and VHF and puts both bands in one handy talkie you can take anywhere!
The TYT MD-2017 operates in analog and digital modes on 400-480MHz frequencies on UHF and 136-174MHz VHF at up to 5 watts of power. It uses Time-Division Multiple-Access (TDMA) digital technology to double the number of users on a single 12.5kHz channel.
The TYT MD-2017 boasts 3000 channels, 10000 contacts, built-in CTCSS/DCS (analog mode only), single call, group call and all call, remote kill/stun/activate, transmit interrupt, VOX, and lone worker function. It is compatible with MOTOTRBO™ compatible, DMR Tier I and II compatible, is firmware upgradeable and is IP67 waterproof.
The TYT MD-2017 is also equipped with the same large color LCD display found on other models in the MD series. It also has the traditional keypad found on the other digital radios, and there are programmable side keys. However, the TYT MD-2017 adds two additional programmable keys, marked P1 and P2.
The TYT MD-2017 also has a trackball, and it’s embedded front and center. This makes the TYT MD-2017 very different indeed.
The TYT MD-2017 dual band digital radio uses Digital Mobile Radio (DMR) Tier 2 Standard protocol. It is compatible with the popular MOTO TRBO series radios using standard encryption, as well as other makes and models of DMR supported radios. It is also compatible with any existing analog two-way radio operating on the supported UHF and VHF frequencies for easy migration to digital technology.
Includes one TYT MD-2017 dual band digital mobile two way radio, dual band antenna, belt clip, AC charger, 3800mAh lithium-ion rechargeable battery, owner’s manual and one year manufacturer warranty.
Features
- Frequency Band:136-174 & 400-480MHz
- Up to 10000 Contacts, 3000 channels, 250 Zones, 64 Channels in each Zon
- IP67 Waterproof
- Use Time-Division Multiple-Access
- (TDMA)digital function Dual time slot for repeater and point to point
- Tri-Power
- GPS
- Lone worker
- Encryption function
- Single/group/all call
- Analog and digital combined Dual Standby
- Remote kill/stun/activate
- Comply with digital protocol ETSI TS 102 361-1,-2,-3
- Color LCD display
- Transmit interruption
- Private/Group call match off = Promiscuous on
- Digital and Analog Monitor mode
- Voice Record
- Voice prompt (Channel Announcement)
- CTCSS/DCS
- Emergency Alarm
- VOX
- TOT
- Talk around
- Squelch
- Keypad lock
- LED Indicator
- Password Lock
- Clock (with time zone)
- Firmware upgradeable
Specifications
General Specification | |
Frequency | 136-174 & 400-480MHz VHF and UHF Dual Band |
Channel | 3000 |
Frequency Stability | ± 1ppm |
Operating Temperature | -30℃~+60℃ |
Operating Voltage | 7.4V DC |
Dimension(Hxuxd) | 131.5*36.8*64 |
Weight | 11.5oz (with battery) |
Battery Type | Li-in |
Battery Capacity | 2200mAh |
Antenna impedance | 50Ω |
Audio output power | 1W @ 16Ω |
Channel Spacing | 12.5KHz |
Transmitter | |
Power (Tri-Power) | UHF≦5W, VHF≧4W |
Transmitter current | Analog≦1.6A Digital≧0.9A |
Standby current | 0.18A |
FM modulation mode | 11K0F3E @ 12.5KHz 14K0F3E @ 20KHz 16K0F3E @ 25KHz |
4FSK digital mode | 12.5KHz (data only0):7K60FXD 12.5KHz (data and voice):7K60FXW |
Modulation distortion | <5% |
Hum & Noise | ≧45dB@25KHz /≧40dB@12.5KHz |
Adjacent channel power | ≦60dB@12.5KHz |
Audio response | +1~-3dB |
Digital protocol | ETSI-TS102 361-1,-2,-3 |
Receiver | |
Analog Sensibility | 0.2μV @ 12dB SINAD |
Digital Sensibility | 0.25μV(BER:5%) |
Adjacent Channel Selectivity | ≦-60dB@12.5KHz |
Co-channel rejection | ≧65dB |
Spurious response | ≧70dB |
Audio response | +1~-3dB |
Rated audio distortion | <5% |
Audio power | 1W |
Modulation noise | ≧45dB@25KHz /≧40dB@12.5KHz |
Package Includes:
1 x TYT MD-2017 GPS Dual Band Digital Radio (DMR)
1 x Antenna
1 x Li-ion Battery 2200mAh
1 x Belt Clip
1 x Charger
1 x Adapter (Input:110-240V 50Hz)
1 x User’s Manual
