AnyTone AT D878UVII Plus DMR & Analog FM APRS GPS Bluetooth Recording 2G ROM Wireless HAM Radios Comunication

Original price was: $468.00.Current price is: $229.00.

+ Free Shipping

AnyTone AT-D878UV II Plus Two Way Radio DMR & Analog FM APRS GPS Bluetooth Recording 2G ROM Wireless HAM Radios Comunication



  • The AnyTone AT878UVII plus radio is a VHF and UHF radio with both Digital DMR (Tier I and II) and Analog capabilities. All the features of the excellent Anytone 868 with the addition of Roaming & Analogue APRS support (Includes GPS as standard)
  • Offering a total of 4,000 channels (Analog and Digital), 10,000 Digital Talk Groups, and up to 150,000 contacts, as well as multiple DMR ID numbers (Radio ID’s) for a single radio.
  • This enables Moonraker to supply it preprogrammed with all UK DMR and analogue vhf/uhf repeaters
  • Supplied with a 3300 mAh battery the radio will give a good working days performance.

The Anytone AT-D878UV is a talky for the DMR digital system (compatible with MOTOTRBO Tier 1 and 2), it is also analogue in FM. Unlike many other DMR equipment, the AT-D878UV offers real VFO function. With it, you can set the desired frequency and configure it as usual, instead of limiting yourself to accessing only pre-programmed memory channels. Of course, the Anytone D878UV also has memory channels, 4000 to be exact. But you do not need to depend on pre-programmed channels. Another difference with other DMR equipment is that it has the possibility to change most of its parameters (not all). Therefore, you do not have to depend on a PC to make any changes to the configuration. However, there are certain parameters, such as the DMR ID, which you can only use with the free PC program.

New The AT-D878UV is the successor to the immensely popular D868UV. The novelty of this radio are, among other things, the APRS functions. The `878 ‘has more internal program memory, which allows the manufacturer to incorporate more functions into the software. For example, you can now configure all APRS parameters through the menu, there is no need to reprogram the code connector for such changes. And another new feature is the ‘roaming’, that is, the function in which a repeater is automatically selected by checking the accessibility of the repeaters from a predefined list of repeaters.
The AT-D878UV has many interesting features. You can memorize 4000 memories (digital and / or analog); 10000 groups or TGs and up to 150,000 contacts. In analog mode, you have functions like DTMF, CTCSS and DCS as well as coding with 2 or 5 tone signals. Also available 1750 Hz tone send. Talky has 5 buttons to which you can assign certain functions, each user can adjust the talky according to their preferences. Its large 1.77 “full color screen has different intensity levels and it looks good, even in sunlight.To save battery, the light on the screen can be turned off with the interval you choose.
It is also good to highlight the possibility of storing multiple DMR ids. Therefore, this talky is valid for professional environments and then, with another ID, for amateur radio bands. For example, several people can share it. The Anytone D878UV has a GPS receiver, so that, if you wish, issue the location of the talky. The AT-D878UV is Bibanda with 2m (VHF) and 70cm (UHF), in both bands you can output analogue or digital DMR. Also, receive in commercial FM (WFM) to listen to your favorite stations. The emission power has 4 values, from 1 to 6w in VHF and 7w in UHF. The headset / microphone connection is compatible with Kenwood or Wouxun. The antenna connector is SMA, the Diamond antennas are excellent, for example those of the “J” class. The programming cable is included with the talky, you will not have to look for it, the programming software is downloaded for free from the manufacturer’s website.

Features:
● Dual-mode ( Digital+Analog)
● 1.77 inch color TFT Screen
● 4000channels
● 10000Talk Groups with 500000 Digital contacts
● ETSI DMR Tier Ⅰ and Ⅱ Compliant
● Auto-senses digital or analog reception
● Ranging function between radios with GPS
● Roaming function

Specification:
General

Frequency Range 144-148MHz (V) , 430-440MHz (U)
Channel Capacity 4000 channels
Channel Spacing 25KHz (Wide Band)
12.5KHz (Narrow Band)
Phase-locked Step 5KHz, 6.25KHz
Operating Voltage 7.4V DC ±20% (3100mAh)
Frequency Stability ±2.5ppm
Operating Temperature -20℃~ +55℃
Size 129×61×42mm (with battery pack)
Weight 293g (with battery pack)
Transmitting Part
Power Output VHF: 7/5/2.5/0.2W, UHF: 6/5/2.5/0.2W
Modulation limit ±5.0KHz@25KHz (Wide Band); ±2.5KHz@12.5KHz (Narrow Band)
Adjacent Channel Power ≥70dB (Wide Band); ≥60dB (Narrow Band)
Hum & Noise ≥40dB (Wide Band); ≥36dB (Narrow Band)
Spurious Emission ≤-36dB (Wide Band); ≤-36dB (Narrow Band)
4FSK Digital Modulation 12.5KHz(data)7K60FXD ; 12.5KHz(data+voice)7K60FXE
Audio Distortion ≤5%
Error rate ≤3%
Receiving Part
Sensitivity (12dB SINAD) ≤0.25μV (Wide Band) 0.3uV/-117.4dBm (BER 5%)
Digital Sensitivity 0.7uV/-110dBm (BER 1%) ≤0.35μV (Narrow Band)
Adjacent Channel Selectivity ≥70dB (Wide Band) ; ≥60dB (Narrow Band)
Spurious Emission ≤-57dB (Wide Band); ≤-57dB (Narrow Band)
Spurious Rejection ≥70dB (Wide Band); ≥70dB (Narrow Band)
Blocking 84db
Hum & Noise ≥45dB (Wide Band);≥40dB (Narrow Band)
Audio Distortion ≤5%
Audio Power Output 1000mW/16Ω

Packing List:
1x AT878UVII plus Radio(2G ROM )  ,recording
1x SMA-Female High Gain Antenna
1x Li-lion Battery
1x Charger Base
1x Plug Adapter
1x Bluetooth PTT Finger
  Key
1x Belt Clip
1x Program Cable
1x User Manual

Weight 0.9 kg
Dimensions 300 × 400 × 180 mm
