Resent RS-918SSB mcHF HF Radio SDR Transceiver 0.5-30MHz CB Mobile Radio
Main functions of HF Radio:
Spectrum Dynamic Waterfall Display
Multiple Working Modes: Receive Mode, Transmit Mode, TUNE Mode, VFO Mode, SPLIT Mode
DSP Digital Signal Processing Noise Reduction
Automatic Notch Filter
Humanized Interface Color Display
Receive Fine Tuning Function, Changeable MIC Gain Value
VCC Power Supply Voltage Indication Table
Transmit Signal Strength Display Table
Multifunctional Instrument: SWR Standing Wave Ratio Meter, AVD Audio Frequency Meter, ALC Signal Modulation Meter
Specification:
Frequency Range – RX:0.5-30MHz TX:All HAM HF BANDS
Operating Mode – SSB(J3E),CW,AM(RX Only), FM, FREE-DV
TX Power – 5W (Standard, DC 13.8V) , 15W (Full,DC 13.8V)
Receiving Sensitivity – 0.11~0.89μV(RFC 50-20)
Minimum Frequency Step – 1Hz
Operating Voltage – DC9~15V
Antenna Impedance – 50Ω
Frequency Stability – ±1.5PPM @ Power on 5 Minutes (Standard) ; ±0.5PPM if Optional TCXO Used
Product Dimension (W × H × D) – 215×74×62mm(Mounting Bracket Included)
Weight – 623g
Frequency Range |
RX: 0.5MHz-30MHz |
TX: All HAM HF Bands | |
Operating Mode | SSB(J3E),CW,AM(RX Only), FM, FREE-DV |
Output Power | 5W (Standard, DC 13.8V) , 15W (Full,DC 13.8V) |
Receiving Sensitivity | 0.11~0.89μV(RFC 50-20) |
Minimum Frequency Step | 1Hz |
Operating Voltage | DC9~15V |
Antenna Impedance | 50Ω |
Frequency Stability | ±1.5PPM Power on 5 Minutes (Standard) ; ±0.5PPM if Optional TCXO Used |
Maximum Current | 3.5A |
Product Dimension (W × H × D) | 190mm*69mm*45mm |
Weight | 632g |
Transceiver comes with automatic key generator circuit. Can be connected to the use of automatic keys |
Standard Accessories:
RS-918SSB HF SDR Transceiver * 1
HM-918 Hand Microphone * 1
MB-918 Mounting Bracket * 1
PL-918 DC Power Cable * 1
